Cylindrical Roller Bearing

NUP SERIES 3

Model Number：NUP SERIES 3

Structure：Cylindrical

Type：Roller

Seals Type：

INQUIRY

Bearing Number	Boundary dimensions(mm)					Basic load ratings(kN)		Limiting speeds(rpm)		Mass(Kg)
JXY	d	D	B	rs min	rs1 min	Cr	Cor	Grease	Oil	(Approx.)
NUP304E	20	52	15	1.1	0.6	31.5	26.9	13,000	15,000	0.176
NUP305E	25	62	17	1.1	1.1	41.5	37.5	11,000	13,000	0.275
NUP306E	30	72	19	1.1	1.1	53	50	9,300	11,000	0.398
NUP307E	35	80	21	1.5	1.1	71	71	8,100	9,600	0.545
NUP308	40	90	23	1.5	1.5	58.5	57	8,000	9,400	0.658
NUP308E	40	90	23	1.5	1.5	83	81.5	7,200	8,500	0.754
NUP309	45	100	25	1.5	1.5	74	71	7,200	8,400	0.877
NUP309E	45	100	25	1.5	1.5	97.5	98.5	6,500	7,600	0.996
NUP310	50	110	27	2	2	87	86	6,500	7,700	1.14
NUP310E	50	110	27	2	2	110	113	5,900	6,900	1.3
NUP311	55	120	29	2	2	111	111	5,900	7,000	1.45
NUP311E	55	120	29	2	2	137	143	5,300	6,300	1.65
NUP312	60	130	31	2.1	2.1	124	126	5,500	6,500	1.8
NUP312E	60	130	31	2.1	2.1	150	157	4,900	5,800	2.05
NUP313	65	140	33	2.1	2.1	135	139	5,100	6,000	2.23
NUP313E	65	140	33	2.1	2.1	181	191	4,600	5,400	2.54
NUP314	70	150	35	2.1	2.1	158	168	4,700	5,500	2.71
NUP314E	70	150	35	2.1	2.1	205	222	4,200	5,000	3.1
NUP315	75	160	37	2.1	2.1	190	205	4,400	5,200	3.28
NUP315E	75	160	37	2.1	2.1	240	263	4,000	4,700	3.74
NUP316	80	170	39	2.1	2.1	190	207	4,100	4,800	3.86
NUP316E	80	170	39	2.1	2.1	256	282	3,700	4,400	4.22
NUP317	85	180	41	3	3	212	228	3,900	4,600	4.54
NUP317E	85	180	41	3	3	291	330	3,500	4,100	4.81
NUP318	90	190	43	3	3	240	265	3,700	4,300	5.3
NUP318E	90	190	43	3	3	315	355	3,300	3,900	5.72
NUP319	95	200	45	3	3	259	285	3,400	4,000	6.13
NUP319E	95	200	45	3	3	335	385	3,100	3,600	6.62
NUP320	100	215	47	3	3	299	335	3,300	3,800	7.49
NUP320E	100	215	47	3	3	380	425	2,900	3,500	8.57
NUP321	105	225	49	3	3	320	360	3,100	3,700	8.53
NUP322	110	240	50	3	3	360	400	3,000	3,500	10
NUP322E	110	240	50	3	3	450	525	2,700	3,100	11.1
NUP324	120	260	55	3	3	450	510	2,700	3,200	12.8
NUP324E	120	260	55	3	3	530	610	2,400	2,800	13.9
NUP326	130	280	58	4	4	560	665	2,500	2,900	17.4
NUP326E	130	280	58	4	4	615	735	2,200	2,600	19.4
NUP328	140	300	62	4	4	615	745	2,300	2,700	21.2
NUP328E	140	300	62	4	4	665	795	2,100	2,400	23.2
NUP330	150	320	65	4	4	665	805	2,100	2,500	25.3
NUP330E	150	320	65	4	4	760	920	1,900	2,300	28.4
